128702-01 BENTLY Input module

Description

128702-01 BENTLY Input module

Product Dimensions：

Product Description

The 128702-01 is the signal processing unit (Proximitor) that works in conjunction with an 8mm probe and an extension cable. Its primary job is to generate a Radio Frequency (RF) signal, send it to the probe, and then convert the reflected signal into a usable voltage output. This voltage is directly proportional to the distance between the probe tip and the target (the rotating shaft).

Product Parameters

Product Advantages

• Superior Accuracy: Provides extremely precise measurements of vibration and position, even in the presence of oil or water on the probe tip.

• Interchangeability: The 3300 XL series allows for the replacement of individual components (probe, cable, or proximitor) without requiring a complete system recalibration.

• High Reliability: Engineered for 24/7 continuous operation in hazardous and high-temperature industrial environments.

• Backward Compatibility: Designed to be physically and electrically compatible with non-XL 3300 series 8mm systems, making it ideal for upgrades.

Key Considerations (Precautions)

• Gap Voltage Calibration: During installation, the probe must be “gapped” correctly (usually set to -10 Vdc at the center of the linear range) to ensure accurate readings.

• Target Material: The standard calibration is for AISI 4140 steel. If your shaft is made of a different alloy (like stainless steel), the output will be inaccurate unless a custom calibration is used.

• Cable Length Matching: The 128702-01 must match the total electrical length of the probe and extension cable (typically 5.0 meters or 9.0 meters). Mixing lengths will lead to significant measurement errors.

• Grounding: Ensure the Proximitor is properly isolated from the machine ground to prevent “ground loops,” which can introduce false vibration signals.

Product Applications

This sensor is a standard in the power generation and oil/gas industries for:

• Radial Vibration: Monitoring the health of sleeve bearings in pumps, motors, and fans.

• Axial Position (Thrust): Detecting “thrust” movement in turbines and compressors to prevent catastrophic internal contact.

• Phase Reference (Keyphasor): Providing a once-per-revolution pulse for speed measurement and vibration phase analysis.

• Eccentricity: Measuring shaft bow or bend during the startup of large steam turbines.
