135489-03 BENTLY Power module

Description

135489-03 BENTLY Power module

Product Dimensions：

Product Description

The 135489-03 is a Position/Prox I/O Module featuring internal terminations. It is designed to receive signals from Proximitor sensors, seismic transducers, or accelerometers. Its primary role is to provide the physical connection points for field wiring and to condition those signals for the 3500 system’s backplane.

Product Parameters

While specific electrical ratings can vary based on the specific monitor it is paired with, the general parameters include:

• Part Number: 135489-03

• Module Type: I/O Module with Internal Terminations.

• Channels: Supports 4 channels (standard for 3500/42M).

• Signal Input: Accepts 4 to 20 mA, Proximitor, or Seismic signals.

• Operating Temperature: -30°C to +65°C (-22°F to +150°F).

• Humidity: 95% non-condensing.

• Mounting: Rear-mount in a 3500 series rack.

Product Advantages

• Reliability: Built to industrial standards for continuous, 24/7 machinery protection.

• Hot-Swappable: Can be replaced without shutting down the entire 3500 rack (depending on system configuration).

• Precision: High-fidelity signal transmission with minimal EMI (Electromagnetic Interference) interference.

• Ease of Integration: Seamlessly interfaces with the 3500/42M monitor to provide vibration and position data.

Key Considerations (Precautions)

• Electrostatic Discharge (ESD): Always use a grounding strap when handling the module to avoid damaging sensitive internal circuitry.

• Configuration: Ensure the jumpers on the main monitor module match the I/O module’s wiring configuration.

• Terminal Tightening: Over-tightening the terminal screws can damage the connector; under-tightening can lead to signal loss.

• Compatibility: Verify that the 135489-03 is compatible with your specific revision of the 3500/42M monitor card.

Product Applications

The 135489-03 is widely used in heavy industries where rotating machinery is critical. Common applications include:

1. Steam and Gas Turbines: Monitoring radial vibration and axial thrust.

2. Compressors: Protecting against surge and mechanical wear.

3. Electric Motors & Generators: Continuous health monitoring of bearings.

4. Pumps: Detecting cavitation or misalignment in high-pressure systems.
