140482-01 BENTLY NEVADA Prox/Velom I/O Module

Description

140482-01 BENTLY NEVADA Prox/Velom I/O Module

Product Dimensions：

Product Description

The Bently Nevada 140482-01 is a critical component within the Bently Nevada 3500 Machinery Protection System, a widely used solution for monitoring the health of industrial machinery. Specifically, the 140482-01 is an I/O (Input/Output) module with external terminations.

This module is designed to work with various monitors in the 3500 system, such as the 3500/42M Proximitor/Seismic Monitor and the 3500/72M Recip Rod Position Monitor. Its purpose is to connect to a variety of sensors and send their signals to the main monitor, which then processes the data and triggers alarms if necessary.

Product Parameters

The 140482-01 is a specialized I/O module, and its full specifications are detailed in the datasheets for the specific monitor it’s paired with (e.g., 3500/42M or 3500/72M). Key parameters include:

• Part Number: 140482-01
• Manufacturer: Bently Nevada (now part of Baker Hughes)
• Product Type: I/O Module with External Terminations
• System Compatibility: Bently Nevada 3500 series
• Input Types: Accepts signals from proximity probes (Proximitors), velocity sensors (Velomitors), and other similar transducers.
• Terminations: External screw-type terminals for easy wiring and maintenance.
• Power Consumption: Typically low, drawing its power from the 3500 rack. For example, a similar module might consume around 1.09W.
• Physical: Designed to be installed in a 3500 rack. The module itself is a circuit board that plugs into a slot in the rack, with the external termination block attached separately.

Key Advantages

• External Terminations: This is the defining feature of the 140482-01. External terminations mean that the wiring from the sensors is connected to a separate terminal block. This allows for easy hot-swapping of the I/O module without disturbing the field wiring, significantly reducing maintenance time and the risk of wiring errors.
• Versatile Sensor Support: The module is compatible with a wide range of Bently Nevada proximity and velocity sensors, making it a flexible solution for monitoring different types of machinery.
• Seamless Integration: As an integral part of the Bently Nevada 3500 system, it works seamlessly with the main monitor and the system’s software, ensuring accurate data collection and reliable protection.
• Rugged Design: Built for industrial environments, the module is designed to withstand typical operating conditions in power plants, oil & gas facilities, and other heavy industries.

Important Notes

• System Specific: The 140482-01 is not a standalone device; it must be used within a Bently Nevada 3500 system.
• Configuration: The module’s behavior (e.g., which parameters to monitor) is configured through the Bently Nevada 3500 Rack Configuration Software, not on the module itself.
• Obsolete Status: Many Bently Nevada 3500 series products are considered legacy or obsolete. While they are still widely used, new installations often use the newer Bently Nevada 3700 or other systems. This may affect availability and support.

Product Applications

The 140482-01 is used in critical machinery protection applications across various industries, including:

• Power Generation: Monitoring radial vibration, thrust position, and casing vibration on steam and gas turbines, generators, and pumps.
• Oil & Gas: Protecting reciprocating compressors, pumps, and other turbomachinery in refineries and pipelines.
• Petrochemical and Chemical Plants: Ensuring the safe and continuous operation of pumps, compressors, and other rotating machinery.
• Industrial Manufacturing: Monitoring the health of large motors, fans, and gearboxes to prevent costly unplanned downtime.
