193-EC1ZZ 193-EIMD Allen-Bradley Power module

Description

193-EC1ZZ 193-EIMD Allen-Bradley Power module

Product Dimensions：

Product Description

The 193-EC1ZZ is an E300 EtherNet/IP Control Module. It serves as the “brain” of the overload relay system, providing the processing power and communication interface. It supports Device Level Ring (DLR) topologies and provides a web server for easy configuration and monitoring.

193-EIMD (Digital I/O Expansion Module)

The 193-EIMD is a Digital I/O Expansion Module that connects to the E300 system. It expands the relay’s capabilities by adding 4 digital inputs and 2 relay outputs (typically rated at 120V/240V AC). This allows the system to manage additional control logic or interlocking features locally.

Product Parameters

Product Advantages

• Modular Design: The “Lego-like” assembly allows you to choose specific sensing, control, and communication modules, reducing inventory costs and providing a custom fit for each motor.

• Advanced Diagnostics: Provides real-time data on current, voltage, power, and energy consumption. It can predict potential failures before they occur (Predictive Maintenance).

• Integrated Ethernet: The 193-EC1ZZ allows for seamless integration into the Rockwell Automation Integrated Architecture, enabling remote monitoring and simplified wiring.

• Reduced Downtime: Quick-connect modules and high-accuracy trip settings prevent unnecessary motor burnouts and speed up troubleshooting through detailed fault logs.

Important Considerations

• Compatibility: Ensure that the Sensing Module (the base that measures current) is compatible with the 193-EC1ZZ and 193-EIMD modules being used.

• Firmware Versions: When replacing a 193-EC1ZZ, ensure the firmware matches the existing system or the Studio 5000 project to avoid communication errors.

• Wiring Safety: Always disconnect power before mounting or removing modules from the DIN rail or sensing base to prevent electrical shock or damage to the internal bus.

• Environmental Limits: Ensure the cabinet has adequate ventilation, as electronic overloads are more sensitive to extreme heat than traditional bimetallic relays.

Product Applications

• Motor Control Centers (MCCs): Used extensively in smart MCCs to provide networked motor protection and data feedback.

• Water/Wastewater: Monitoring pump performance and protecting against dry-run or jam conditions.

• Oil and Gas: Remote monitoring of motors in hazardous or hard-to-reach locations via EtherNet/IP.

• Manufacturing: Precision protection for conveyor systems, fans, and mixers where downtime results in significant production loss.
