2093-AMP1 Allen Bradley Central control module

Description

2093-AMP1 Allen Bradley Central control module

Product Dimensions：

Product Description

The 2093-AMP1 is a single-width inverter module that provides power and control for one servo motor. It does not have its own AC-to-DC converter; instead, it draws DC bus power from a 2093-ACxx Integrated Axis Module (IAM) via a 2093-PRSx power rail. This “follower” design allows multiple 2093-AMP1 modules to be snapped onto a single rail, creating a highly space-efficient multi-axis drive system.

Note: As of December 31, 2022, this series has been discontinued by Rockwell Automation. The recommended replacement is the Kinetix 5300 series (e.g., 2198-C1004-ERS).

Product  Parameters

Product Advantages

• Ultra-Compact Footprint: The single-width design is one of the narrowest in the industry, allowing for extremely high axis density in control panels.

• Efficient Power Sharing: Because it shares a common DC bus with other modules on the rail, energy generated during motor braking can be used by other axes, improving overall system energy efficiency.

• Simplified Assembly: The “plug-and-play” power rail mounting eliminates traditional wiring between the converter and inverter, reducing labor and potential wiring errors.

• High-Speed Synchronization: Works seamlessly within a SERCOS interface network for microsecond-level coordination between multiple axes.

Safety and Maintenance

• IAM Dependency: The 2093-AMP1 cannot operate alone. It must be connected to an Integrated Axis Module (IAM) to receive DC bus power and control signals.

• Power Rail Integrity: Ensure the power rail (2093-PRSx) pins are clean and free of debris before mounting. Damaged pins can cause intermittent DC bus faults.

• Static Sensitivity: This unit contains sensitive electronics. Use standard ESD (Electrostatic Discharge) precautions during installation or replacement.

• Residual Energy: Even after the main IAM is powered down, the DC bus can hold a charge. Always wait at least 5 minutes and verify with a voltmeter before touching terminals.

Typical Applications

The 2093-AMP1 is ideally suited for low-power, high-precision motion control:

• X-Y Tables: Multi-axis positioning for laboratory automation or laser cutting.

• Electronic Assembly: High-speed pick-and-place robots and circuit board testing machines.

• Packaging: Synchronized labeling, capping, or small-scale pouch filling.

• Medical Devices: Precision fluid dispensing and automated sample handling.

• Textile Machinery: Managing multiple small spindles or tension rollers.
