2093-PRS1 Allen-Bradley Controller module

Description

2093-PRS1 Allen-Bradley Controller module

Product Dimensions：

Product Description

The 2093-PRS1 is a specialized backplane (power rail) designed for the Kinetix 2000 series. Its primary role is to house one Integrated Axis Module (IAM). The rail distributes logic power, control signals, and the shared DC bus voltage from the IAM to any attached inverter modules. It is an “open type” device meant for installation inside an industrial enclosure.

Product Parameters

Product Advantages

• Integrated Design: Dramatically reduces wiring time by using a common backplane for power and control signals, eliminating the need for complex daisy-chain wiring between drives.

• Space Efficiency: The slim, “zero-stack” design allows for a very compact footprint within the control cabinet, saving valuable panel space.

• Ease of Maintenance: Drive modules can be easily plugged into or removed from the rail, simplifying system upgrades or repairs.

• Reliability: Features conformal-coated connection pins to resist environmental contaminants and ensure long-term electrical integrity.

• Enhanced Safety: When used with slot fillers, it prevents accidental contact with live bus voltages in unused slots.

Important Considerations

• Vertical Mounting: The power rail must be mounted vertically (within 3° of vertical) to ensure proper airflow and cooling for the attached modules.

• Slot Fillers: Any unused slot on a multi-axis rail (or the remaining capacity on the PRS1 if only an IAM is used) should be covered with a 2093-PRF Slot Filler to prevent electrical shock and maintain the continuity of the contactor enable string.

• Power-Off Installation: Never install or remove modules while power is applied to the rail. Doing so can cause arcing and permanent damage to the connector pins.

• Grounding: Ensure the rail is mounted to a grounded, conductive subpanel. Use the provided ground straps to ensure a low-impedance path to machine ground.

Product Applications

The 2093-PRS1 is typically used in low-to-medium power motion control applications where precision and space are critical:

1. Packaging Machinery: Used in labeling, filling, and small-scale cartoning machines.

2. Electronic Assembly: Ideal for pick-and-place machines or high-speed testing equipment.

3. Food & Beverage: Used in processing lines requiring coordinated motion for conveyor synchronization.

4. Pharmaceuticals: Precise dosing and bottling systems.

5. General OEM Machines: Any small machine requiring a single axis of integrated motion via the Rockwell Logix platform (e.g., CompactLogix).
