22B-D6PON104 Allen-Bradley AC DRIVE MODULE

Product Advantages

• Compact Design: The PowerFlex 40 series is known for its small footprint, making it ideal for installations where space is limited.
• Ease of Use: The integral keypad and intuitive programming interface simplify setup and operation, even for users new to VFDs.
• Cost-Effective: Offers a good balance of features and performance at a competitive price point for general-purpose applications.
• Built-in Features: Includes an integral keypad, Modbus RTU communication, and a dynamic braking transistor, reducing the need for external components.
• Reliable Performance: Designed for robust operation in industrial environments, contributing to improved process control and energy efficiency.
• Global Compatibility: Adheres to international standards, facilitating use in diverse regions.

Precautions

• Input Power: Ensure the input power supply matches the drive’s specifications (480V AC, 3-phase). Incorrect voltage can damage the drive.
• Motor Compatibility: Ensure the motor’s voltage and current ratings are compatible with the drive’s output. The drive should be sized appropriately for the motor and application load.
• Grounding: Proper grounding of the drive and motor is critical for safety and to prevent electrical noise issues. Follow all local electrical codes and Rockwell Automation guidelines.
• Environment: Install the drive in an environment within its specified temperature and humidity ranges. Avoid direct sunlight, excessive dust, moisture, or corrosive gases. The NEMA/UL Type Open enclosure requires installation within a suitable control cabinet.
• Dynamic Braking: If dynamic braking is required for fast deceleration, an external dynamic braking resistor must be connected. Ensure the resistor is correctly sized and wired.
• Parameter Settings: Carefully configure drive parameters based on your motor and application requirements. Incorrect settings can lead to poor performance, motor damage, or unsafe operation.
• Service and Maintenance: Only qualified personnel should install, program, and maintain the drive. Disconnect all power before servicing.

Product Applications

The Allen-Bradley PowerFlex 40 drive (22B-D6P0N104) is well-suited for a variety of general-purpose motor control applications where speed control and energy savings are beneficial. Common applications include:

• Conveyors: Controlling the speed of material handling systems to optimize flow and prevent product damage.
• Fans and Pumps: Adjusting fan and pump speed based on demand, leading to significant energy savings in HVAC, water treatment, and industrial fluid transfer systems.
• Small Machines: Providing precise speed control for machines like mixers, grinders, and packaging equipment.
• Machine Tools: Basic speed control for operations like drilling, milling, or turning.
• Textile Machinery: Regulating the speed of various textile processes.
• Food and Beverage: Controlling processes like filling, mixing, and conveying in hygienic environments (when installed in a suitable enclosure).
