56RF-IN-IPS12 Allen-Bradley RFID interface module

Description

56RF-IN-IPS12 Allen-Bradley RFID interface module

Product Dimensions：

Product Description

The NI SHC68-68-EPM is a shielded cable designed for connecting various NI data acquisition (DAQ) and switch devices to their respective terminal blocks or accessories. The cable features a 68-pin VHDCI connector on one end and a 68-pin male D-Sub connector on the other. It is specifically engineered to ensure high-quality signal transmission and to minimize noise interference in measurement systems. The “EPM” designation often refers to its optimized design for applications requiring superior signal integrity.

Product Specifications

• The 56RF-IN-IPS12 is a robust, single-channel RFID interface block.
  • Manufacturer: Allen-Bradley (Rockwell Automation)
  • Part Number Breakdown:
    • 56RF: The Bulletin series for high-frequency (13.56 MHz) RFID systems.
    • IN: Indicates that it’s an Interface Block.
    • IPS12: Specifies the configuration of the block:
      • I: One input port.
      • P: One RFID transceiver port.
      • S: The input is a sink-type (24V DC).
      • 12: Indicates a single channel with one input and one output.
  • Communication Protocol: EtherNet/IP (10/100 Mbps)
  • RFID Frequency: 13.56 MHz (High Frequency)
  • Power Supply: 24V DC (-20% to +10%)
  • Ingress Protection (IP) Rating: IP67 and IP69K. This means it is dust-tight and protected against powerful water jets and high-pressure, high-temperature washdowns. This rating allows for direct installation on machines without the need for an additional enclosure.
  • Dimensions (H x W x D): Approximately 179 mm x 37 mm x 43.25 mm.
  • Weight: Approximately 0.2 kg (0.45 lbs).
  • Mounting: Panel or DIN rail mounting.
  • Connectors: M12 connectors for network, auxiliary power, I/O, and the RFID transceiver.
  • Indicators: LEDs for network status, link status, auxiliary power, and I/O status.

  Product Advantages

  • Direct Integration with EtherNet/IP: This device seamlessly integrates with an EtherNet/IP network, making it easy to connect to Allen-Bradley Logix controllers and other EtherNet/IP-compatible devices. This eliminates the need for complex, proprietary communication setups.
  • High-Frequency RFID: Operating at 13.56 MHz, it is well-suited for applications that require reliable reading and writing of data at short to medium distances, making it ideal for tracking parts on an assembly line.
  • Durable and Compact Design: The IP67 and IP69K ratings ensure the device can withstand harsh industrial environments, including exposure to dust, moisture, and washdowns. Its compact form factor allows it to be mounted directly on a machine, saving space and simplifying wiring.
  • Flexible I/O: The built-in input and output points allow for local control and signaling, which can be useful for triggering a read or controlling a nearby indicator light directly from the block.
  • Simplified Wiring: The use of M12 connectors simplifies wiring and reduces installation time and potential for errors.

  Precautions

  • Power Supply: The device requires a specific 24V DC power supply. Ensure the power source is clean, stable, and correctly fused to avoid damage.
  • Network Configuration: Proper EtherNet/IP network configuration is critical. You must correctly set the IP address and other network parameters to ensure communication with the PLC.
  • Mounting Location: While the device is highly durable, it’s best to mount it in a location where it won’t be subjected to excessive mechanical stress or high temperatures outside its specified operating range.
  • Antenna Selection: The performance of the RFID system depends on the correct choice of antenna (transceiver) and its placement. Ensure the selected antenna is compatible with the interface block and positioned to provide a clear read/write field.

  Product Applications

  The Allen-Bradley 56RF-IN-IPS12 is a key component for industrial applications requiring automated tracking and data collection.

  • Manufacturing and Assembly: Tracking parts, tools, or products as they move along a production line to ensure correct assembly, quality control, and process verification.
  • Material Handling and Logistics: Improving inventory management and traceability in warehouses by tracking pallets, containers, or assets as they are moved by automated guided vehicles (AGVs) or conveyor systems.
  • Machine Tooling and Robotics: Identifying tools or fixtures on a robotic arm or CNC machine to ensure the correct program is selected and executed, or to track tool usage and maintenance.
  • Pharmaceutical and Food & Beverage: Automating batch traceability and ensuring compliance with regulatory requirements by tracking product containers or raw material bins in sanitary environments.
  • Secure Access Control: Providing automated authentication for equipment or restricted areas by reading personnel badges or tags on moving vehicles.
