7BP706.0 B&R Input module

Description

7BP706.0 B&R Input module

Product Dimensions：

Product Description

The B&R 7BP706.0 is a module rack for the B&R System 2003 series. It is a fundamental component of the control system, serving as the physical backplane that holds and connects various I/O and specialty modules to the central processing unit (CPU). This rack provides the necessary power and communication bus to all the installed modules.

This specific model is a 6-slot module rack. This means it can accommodate up to six of the modular I/O or specialty components from the B&R System 2003. The rack’s structure includes the necessary left and right side sections, which are used to mount the rack and provide the physical and electrical connections for the entire bus system.

Product Parameters

• Product Type: Module Rack / Backplane
• Series: B&R System 2003
• Number of Slots: 6
• Included Components: The rack assembly includes the backplane for six modules as well as the left and right end sections for mounting and bus termination.
• Function: Provides the communication bus and power distribution for up to six B&R System 2003 modules.

Product Advantages

• Modular Design: The rack-based system allows for a flexible and scalable control system. You can choose and combine different I/O and specialty modules to perfectly match your application’s needs.
• Simplified Wiring: By providing a common backplane, the rack simplifies the wiring and reduces the complexity of the control panel. All modules are connected to the CPU through the rack, not with individual wires.
• Robust Construction: As part of the industrial-grade System 2003, the rack is built to be durable and reliable in demanding factory environments.

Important Notes

• Obsolete Status: The B&R System 2003 is an older, now obsolete product line. This means that finding new units may be difficult, and you will likely need to source refurbished or used parts. For new designs, it’s recommended to use a current B&R product family.
• System Specificity: This rack is exclusively for the B&R System 2003. It is not compatible with modules from newer B&R series (like the X20) or other manufacturers.
• Correct Installation: Proper installation of the modules into the rack and securing the end sections is crucial for reliable electrical and communication connections.

Product Applications

The 7BP706.0 rack, as part of the B&R System 2003, was used in a wide range of industrial automation applications where modularity and flexibility were key requirements.

• Machine Automation: Providing the central foundation for the I/O of various machines, from packaging to assembly lines.
• Process Control: Used in systems for controlling valves, sensors, and actuators in a process plant.
• Discrete Manufacturing: Serving as the backbone for control systems in factories with multiple, distinct machines.
