8AC114.60-2 B&R Power Supply Module

Description

8AC114.60-2 B&R Power Supply Module

Product Dimensions：

Product Description

The B&R 8AC114.60-2 is an ACOPOS plug-in module with a POWERLINK V2 interface. This module is a critical component for B&R’s ACOPOS series of servo drives, enabling high-speed, real-time communication for demanding motion control applications. It’s designed to be easily installed into a compatible ACOPOS servo drive to extend its networking capabilities.

Product Details

This plug-in module is a key part of an advanced motion control system. Its main function is to provide an interface for the POWERLINK protocol, which is a real-time industrial Ethernet standard. This allows for rapid and synchronized data exchange between the central controller and the servo drive. A significant feature of this module is the integrated 2-port hub, which simplifies network wiring and allows for various topologies, such as star or line, without needing a separate external hub.

Product Parameters

• Product Type: ACOPOS plug-in module, POWERLINK V2 interface
• Compatibility: Designed for use with B&R ACOPOS servo drives
• Interface: POWERLINK V2
• Communication Rate: 100 Mbit/s
• Network Ports: 2x RJ45 ports (integrated hub)
• Topology Support: Star or tree
• Power Consumption: Max. 3 W
• Status Indicators: Status LED + 2x Link LEDs
• Node Number: Configurable via switches on the module
• Electrical Isolation: Yes, for reliable network operation
• Dimensions: Small form factor for slot mounting in an ACOPOS drive

Product Advantages

• High-Speed Communication: The POWERLINK V2 interface provides a real-time, high-speed network for time-critical applications, ensuring precise synchronization and control of servo axes.
• Simplified Wiring: The integrated 2-port hub significantly reduces cabling complexity and costs, making it easier to set up a network without external networking hardware.
• Flexible Network Topologies: The hub allows for both star and line topologies, providing greater flexibility in designing the machine or plant layout.
• Easy Configuration: The POWERLINK node number can be set directly on the module using switches, simplifying network setup and maintenance.
• System Integration: It’s a seamlessly integrated component of the B&R ACOPOS system, which ensures compatibility and straightforward programming within the B&R development environment.

Important Notes

• System Specificity: This module is designed exclusively for use with B&R ACOPOS servo drives. It is not a standalone device and won’t work with other drive systems.
• Proper Installation: The module must be correctly plugged into the designated slot on the ACOPOS drive. Ensure the drive is powered off before installation or removal.
• Configuration: The POWERLINK node number must be configured correctly for proper network communication. Refer to the ACOPOS user’s manual for detailed instructions.

Product Applications

The 8AC114.60-2 module is essential for applications that require high-performance, synchronized motion control.

• Robotics: For multi-axis robot control where precise, real-time coordination of all joints is crucial.
• Packaging Machinery: In complex packaging lines that need synchronized motion for cutting, sealing, and product handling.
• Machine Tools: Used in CNC machines and other precision machine tools for coordinated motion of multiple axes.
• Printing and Converting: For controlling the speed and position of rollers and cutters in printing presses and other converting equipment.
