BV1045.00-2 B&R Output module

Description

BV1045.00-2 B&R Output module

Product Dimensions：

Product Description

The BV1045.00-2 is a bus receiver module designed to expand the capabilities of B&R industrial control systems. It is primarily used to connect multiple expansion racks to a central controller, allowing for a modular and distributed architecture. This module facilitates the transmission of I/O data and synchronization signals across the backplane, ensuring that even remote I/O points operate with high-speed deterministic timing.

Technical Specifications

Product Advantages

• High-Speed Data Transfer: Optimized for the 2005 system backplane, ensuring minimal latency when communicating between expansion racks.

• Modular Scalability: Allows users to extend the number of I/O points significantly without needing to upgrade the main CPU.

• Robust Hardware Design: Built to withstand industrial environments, featuring high electromagnetic compatibility (EMC) and vibration resistance.

• Plug-and-Play Integration: Once installed in the rack and configured in B&R Automation Studio, the module is recognized automatically by the system logic.

• Galvanic Isolation: Protects the central control logic from electrical noise or surges originating in the expansion racks.

Precautions

• Rack Compatibility: Ensure the BV1045.00-2 is installed in a compatible B&R 2005 series rack (e.g., BP or BP-series backplanes).

• Power Down Before Handling: Always disconnect the power supply from the rack before inserting or removing the module to prevent electrical arcing or damage to the backplane pins.

• Address Settings: If the module requires hardware addressing via DIP switches (depending on the specific revision), ensure they are set correctly to avoid network conflicts.

• Cable Integrity: When connecting multiple racks, use only B&R approved high-quality expansion cables to maintain signal integrity and timing accuracy.

Product Applications

The B&R BV1045.00-2 is widely utilized in large-scale automation projects, including:

• Complex Machinery: Used in plastic injection molding machines or packaging lines where high I/O counts are required across different sections of the equipment.

• Distributed Control Systems: Ideal for factory floor automation where sensors and actuators are physically separated from the main control cabinet.

• Retrofitting and Upgrades: Often used to expand existing B&R legacy systems where additional functionality or more sensors are being added to an older production line.

• Testing and Simulation: Employed in large-scale test benches where multiple measurement modules must be synchronized with a single controller.
