CC-IP0101 Honeywell PROFIBUS DP Gateway Module

Description

CC-IP0101 Honeywell PROFIBUS DP Gateway Module

Product Dimensions：

Product Description

The Honeywell CC-IP0101 is a PROFIBUS DP Gateway Module, a key component for industrial automation systems. Its main purpose is to act as a bridge, allowing seamless communication between a Honeywell Experion PKS or Experion LX control system and a PROFIBUS DP fieldbus network. This gateway module enables the control system to communicate with and manage a wide array of field devices like sensors, actuators, and controllers that are on the PROFIBUS network.

Product Parameters

• Model Name: PROFIBUS DP Gateway Module
• Part Number: CC-IP0101
• Module Type: Gateway Module
• Compatibility: Honeywell Experion PKS and Experion LX systems, particularly with the C300 controller.
• Supported Devices: Can support up to 127 PROFIBUS DP devices.
• Communication: PROFIBUS DP-2 protocol, with support for baud rates from 9.6 kbps to 12 Mbps.
• Operation Modes: Supports both master and slave operation.
• Power Supply: Powered by the Experion LX system.
• Operating Temperature: -40°C to 85°C (-40°F to 185°F).
• Dimensions: Approximately 190 mm x 69 mm x 23 mm (7.5 in x 2.7 in x 0.9 in).

Product Advantages

• Seamless Integration: The CC-IP0101 enables seamless integration of PROFIBUS DP devices into Honeywell’s control systems. This is particularly valuable for applications that need to combine devices from different manufacturers.
• High-Speed Communication: By supporting a wide range of baud rates up to 12 Mbps, the module facilitates fast and efficient data transfer, which is crucial for real-time control and monitoring.
• Versatility: The ability to support up to 127 devices and operate in both master and slave modes makes this module highly flexible and suitable for complex and extensive automation setups.
• Durability: Designed for industrial environments, the module can withstand extreme temperatures and is built to be reliable in harsh conditions.

Precautions

• System Compatibility: Ensure that your Honeywell control system (e.g., Experion PKS, Experion LX with a C300 controller) is compatible with this module.
• Professional Installation: As this is a critical communication component in an industrial control system, installation and configuration should be carried out by a qualified technician.
• Network Configuration: Proper configuration of the PROFIBUS network and the module itself is essential for reliable communication. Incorrect settings can lead to data errors or system failure.
• Wiring: Always follow the wiring diagrams and instructions in the official product manual to ensure secure and correct connections.

Product Applications

The Honeywell CC-IP0101 gateway module is used in a variety of industries that rely on PROFIBUS technology for communication between their control systems and field devices. Common applications include:

• Process Control: In chemical plants, refineries, and other process industries, it’s used to integrate and control PROFIBUS-enabled instruments and actuators.
• Manufacturing and Automation: Facilitating communication between a Honeywell control system and automation equipment like drives, sensors, and robots on a production line.
• Building Automation: Integrating building management systems with field devices to control HVAC, lighting, and other building functions.
