EA9-T8CL AutomationDirect Communication module

Description

EA9-T8CL AutomationDirect Communication module

Product Dimensions：

Product Description

The EA9-T8CL is a member of the C-more EA9 series, featuring an 8.4-inch LED-backlit liquid crystal display (LCD). It is a powerful interface tool that allows operators to monitor and control industrial processes. This model is known for its vibrant color depth (64k colors) and a high-speed 800 MHz processor that ensures smooth screen transitions and fast data sampling. It supports a wide array of industrial protocols, making it compatible with various PLCs (Programmable Logic Controllers) and other field devices.

Product Parameters

• Display Size: 8.4-inch diagonal.

• Display Type: TFT Color LCD with LED backlight.

• Resolution: 800 x 600 pixels (SVGA).

• Processor: 800 MHz RISC CPU.

• Memory: 26 MB of project memory.

• Communications: * One Ethernet 10/100 Base-T port.

  • Three Serial ports (RS-232, RS-422/485).

  • Two USB 2.0 Type A ports (for memory sticks or HID devices).

  • One USB 2.0 Type B port (for programming).

• Input Voltage: 12–24 VDC.

• Operating Temperature: 0 to 50°C (32 to 122°F).

• Environmental Rating: NEMA 4/4X, IP65 (indoor use only).

Product Advantages

• High Visibility: The SVGA resolution and high brightness (350 nits) ensure that the display is easily readable even in well-lit factory environments.

• Remote Access: Supports a built-in web server and remote access features, allowing users to monitor the HMI via smartphones, tablets, or PCs.

• Extensive Connectivity: With multiple serial ports and Ethernet, it can communicate with multiple different brands of PLCs simultaneously.

• User-Friendly Software: The C-more programming software offers a vast library of objects, built-in simulators, and easy drag-and-drop configuration.

• Data Logging: Features an integrated SD card slot for logging historical data, trends, and alarms without requiring a constant PC connection.

Important Considerations and Precautions

• Power Supply: Ensure a stable 12–24 VDC power source is used; exceeding the rated voltage can permanently damage the internal circuitry.

• Touch Screen Care: Use only fingers or specialized plastic styluses on the resistive touch screen. Sharp objects like screwdrivers or pens can puncture the overlay.

• Chemical Exposure: While the front panel is NEMA 4X rated, avoid direct exposure to harsh solvents or abrasive cleaning agents that could degrade the plastic surface.

• Firmware Compatibility: Ensure that the C-more programming software version on your PC matches or supports the firmware version installed on the EA9-T8CL hardware.

Product Applications

• Automated Manufacturing: Real-time monitoring of assembly lines, production counts, and machine status.

• Packaging Machinery: Managing complex timing sequences and recipe management for different packaging formats.

• Water and Wastewater: Visualizing tank levels, pump status, and flow rates in municipal or industrial treatment plants.

• HVAC Systems: Centralized control for building management systems, including temperature setpoints and energy usage tracking.

• Food and Beverage: Interfacing with pasteurizers, mixers, and bottling equipment where hygiene and clear status updates are required.
