F0-08ADH-1 AutomationDirect Interface module

Description

F0-08ADH-1 AutomationDirect Interface module

Product Dimensions：

Product Description

The F0-08ADH-1 is an 8-channel, 16-bit current analog input module. This module allows a DL05 or DL06 PLC to interface with high-precision industrial sensors that output standard current signals (0-20mA or 4-20mA). Because it offers 16-bit resolution, it provides significantly higher accuracy than standard 12-bit modules, making it suitable for processes where minute changes in data are critical.

Product  Parameters

Product Advantages

• High Density: Provides 8 analog channels while occupying only one expansion slot, preserving space for other modules.

• Superior Precision: The 16-bit resolution ($0$ to $65,535$ counts) allows for extremely fine measurements, such as precise pressure or chemical level monitoring.

• Cost-Effective: Offers a professional-grade analog interface at a fraction of the cost of larger modular PLC systems.

• Easy Integration: Uses the standard V-memory pointers in DirectSOFT programming, making it easy to map sensor data to the PLC logic.

• Jumpers for Range: Simple hardware jumpers allow you to switch between 0-20mA and 4-20mA configurations without complex software changes.

Safety and Maintenance

• Single-Ended Inputs: This module uses a single common for all 8 channels. Ensure that your sensors are compatible with a common-ground configuration to avoid ground loops.

• Twisted Pair Wiring: To maintain the 16-bit accuracy, use shielded twisted-pair cable for all analog signals and ground the shield at the PLC end only.

• Slot Limitation: In a DL05, only one slot is available. In a DL06, you have two slots; if using two analog modules, verify the total power budget of the PLC base.

• Current Loop Warning: Do not apply voltage directly to the current inputs without a current-limiting resistor, as this may damage the $250 \Omega$ precision resistors on the board.

Typical Applications

• Precision Process Control: Monitoring flow rates, pressure, or temperature in chemical or food processing where high accuracy is required.

• Water Treatment: Tracking tank levels or PH levels across 8 different stages using 4-20mA sensors.

• Environmental Monitoring: Interfacing with gas sensors or humidity transmitters for greenhouse or laboratory control.

• Oil and Gas: Remote monitoring of pipeline pressure transducers.

• HVAC Systems: Controlling multiple variable frequency drives (VFDs) feedback loops or air quality sensors.
