KJ1501X1-BC2 EMERSON Processor module

Description

KJ1501X1-BC2 EMERSON Processor module

Product Dimensions：

Product Description

The KJ1501X1-BC2 is a 24V DC to 12V DC converter. It takes bulk 24V DC power from an external source and converts it to the 12.25V DC required to power the internal circuitry of the DeltaV modules sitting on the same carrier. The “BC2” is an earlier iteration within the BC series, serving as a foundational power component for M-series hardware.

Product Parameters

Product Advantages

• Modular Redundancy: Two KJ1501X1-BC2 modules can be installed on a redundant carrier. If one unit fails, the other takes over the full load without interrupting the process.

• Wide Operating Range: The module is designed for “Extended Temperature” environments, allowing it to function reliably in harsh industrial field cabinets.

• Diagnostic Reporting: Integrated with the DeltaV Explorer; the system can detect if the power supply is present, functioning, or if the input voltage has dropped.

• Conformal Coating: Standard protection against G3 (Harsh) environmental contaminants, preventing corrosion in chemical or heavy industrial settings.

• Easy Maintenance: Features a simple “snap-in” mechanical design that requires no tools for physical installation or removal.

Important Considerations & Precautions

1. Redundancy Check: If you are replacing a module in a redundant pair, ensure the second module is healthy (indicated by the green LED) before removing the faulty one.

2. Carrier Loading: A single power supply can support multiple I/O modules, but the total current draw must not exceed 13A. Large configurations may require careful power auditing.

3. Hazardous Areas: Do not disconnect or connect the module while the circuit is live unless the area is known to be non-hazardous.

4. Compatibility: Ensure your carrier version supports the BC2 revision. While mostly backward compatible, always verify with your specific DeltaV software version (v11 or higher is standard for this series).

Product Applications

• Process Automation: Providing the “heartbeat” power for DeltaV controllers in chemical plants and refineries.

• Distributed I/O: Powering remote I/O nodes located across a facility to reduce wiring costs.

• Critical Control Loops: Used in applications where power failure would result in significant production loss or safety risks.

• Pulp and Paper / Mining: Robust enough for the high-vibration and dusty environments typical of these industries.
