MC-41103400 SCHNEIDER Motor Driver

Description

MC-41103400 SCHNEIDER Motor Driver

Product Dimensions：

Product Description:

The Schneider MC-41103400 is a robust and compact PacDrive MC-4 series servo drive. Its primary function is to provide highly precise control over rotary and linear servo motors. Working as part of a complete motion control system, it takes commands from a motion controller (typically another PacDrive unit) and translates them into exact motor movements, meticulously managing speed, position, and torque. Its small size allows it to be easily integrated into machinery where space is limited.

Product Parameters

While specific parameters can vary slightly based on the exact revision, here are the general specifications for the Schneider MC-41103400:

• Manufacturer: Schneider Electric (often associated with ELAU, a Schneider brand known for motion control).
• Product Type: AC Servo Drive / PacDrive Servo Drive
• Model Series: MC-4 (e.g., MC-4/11/03/400)
• Rated Current: Typically around 10A (Amperes). Note that some specific configurations or older listings might indicate 3A; always verify with the official datasheet or your supplier.
• Rated Voltage: 400V AC, designed for 3-phase industrial power supplies (generally compatible with 380-480V AC systems).
• Control Interface: Often integrates into an EtherCAT network within the PacDrive architecture for communication.
• Dimensions (Approximate):
  • Height: 260 mm
  • Width: 69 mm
  • Depth: 260 mm
• Weight: Approximately 2.98 – 3.0 kg (6.57 – 6.61 lbs).
• Protection Rating: Typically IP20 (suitable for mounting inside a control cabinet).
• Environmental Conditions: Built for industrial environments, with specified operating and storage temperature ranges.
• Compliance: Adheres to relevant industrial standards and regulations (e.g., REACh, EU-RoHS).

Product Advantages

• Exceptional Precision: Designed for applications demanding highly accurate and repeatable motion, vital for complex machinery.
• Dynamic Performance: Offers excellent dynamic response, enabling rapid acceleration, deceleration, and precise positioning, which translates to higher machine throughput.
• Space-Efficient: Its relatively small footprint helps optimize space within control cabinets and machinery.
• Built to Last: Constructed for continuous, reliable operation in demanding industrial environments, ensuring durability and minimal downtime.
• Seamless Integration: As a core component of the Schneider PacDrive system, it integrates smoothly with PacDrive controllers and other motion components, simplifying system design and commissioning.
• Optimized for Packaging: Particularly well-suited for high-speed and intricate packaging applications due to its superior performance characteristics.

Precautions

When installing, operating, or maintaining the Schneider MC-41103400, keep these critical precautions in mind:

• Qualified Personnel: Only qualified and authorized personnel familiar with electrical systems, motion control, and safety procedures should perform installation, wiring, commissioning, and maintenance.
• Power Isolation: Always ensure all power sources to the servo drive and related machinery are completely disconnected and locked out before any work. Verify zero voltage with a properly rated voltage sensing device.
• Proper Grounding: Correctly grounding the servo drive and motor is essential for both safety and to minimize electromagnetic interference (EMI).
• Wiring Standards: Adhere to all local and international electrical codes and wiring practices. Always use shielded cables for motor and encoder connections to maintain signal integrity and reduce electrical noise.
• Thermal Management: Ensure adequate ventilation and cooling within the control cabinet to prevent the drive from overheating. Observe the specified ambient temperature limits.
• Firmware Compatibility: Verify that the firmware versions of the servo drive and the connected PacDrive controller are compatible to avoid operational issues.
• Motor Matching: Use the servo drive only with compatible servo motors as specified by Schneider Electric to ensure optimal performance and prevent damage.
• Mechanical Safety: Before activating the drive, ensure all mechanical components connected to the motor are properly installed, guarded, and free from obstructions.
• Consult Documentation: Always refer to the official Schneider Electric / ELAU PacDrive documentation, including the installation manual and user guide, for the most detailed instructions, wiring diagrams, and safety information specific to this model.

Product Applications

The Schneider MC-41103400, being a high-performance servo drive, is primarily used in industries and applications that demand precise, synchronized, and dynamic motion control. Its notable use as a spare part for blister packing machines highlights a key application area.

Common applications include:

• Packaging Machinery:
  • Blister Packing Machines: A primary application, where precise control of forming, filling, sealing, and cutting processes is critical.
  • Filling and Capping Machines: Ensuring accurate volumetric filling and precise capping.
  • Cartoning Machines: Coordinated movement for forming, loading, and sealing cartons.
  • Flow Wrappers and Labeling Machines: Achieving high-speed, precise synchronization for wrapping and accurate label placement.
• Printing and Converting:
  • Printing Presses: Ensuring exact registration and web tension control.
  • Cut-to-Length Machines: Providing precise material feeding and cutting.
• Robotics: Controlling multi-axis robotic systems for assembly, pick-and-place tasks, and welding.
• Material Handling: Used in automated guided vehicles (AGVs), gantry systems, and for synchronizing conveyors.
• General Automation: Any industrial application requiring high-accuracy speed, position, and torque control of an electric motor.
