MSI-M/R Leuze Central control module

Description

MSI-M/R Leuze Central control module

Product Dimensions：

Product Description

The 716M12 is a 16-port managed switch utilizing M12 connectors instead of standard RJ45 ports. These screw-locking connectors provide a water-tight and vibration-resistant connection, making the switch ideal for transit, mining, and maritime industries. As a fully managed switch, it offers advanced network configuration tools, including VLAN tagging, Quality of Service (QoS), and N-Ring™ technology for high-speed network redundancy.

Product Parameters

Product Advantages

• Extreme Durability: The IP67 rating and M12 connectors ensure that the switch can be mounted directly on machinery or outdoor structures without a protective NEMA enclosure.

• Superior Redundancy: With N-Ring technology, the switch can recover from a network ring failure in approximately 30 milliseconds, ensuring nearly zero downtime for critical processes.

• Traffic Management: Supports IGMP Snooping and VLANs, which are essential for managing Multicast traffic in complex industrial automation environments (such as EtherNet/IP networks).

• Remote Monitoring: Includes N-View™ OPC monitoring software, allowing maintenance teams to view real-time switch health and port status from a central control room.

Important Considerations

• Cable Compatibility: This switch requires specialized M12 D-coded cable assemblies. Standard RJ45 Ethernet cables cannot be used without ruggedized adapters.

• Proper Sealing: To maintain the IP67 rating, all unused ports must be covered with the appropriate M12 protective caps.

• Grounding: In high-interference environments, ensure the switch chassis is properly grounded to the vehicle or machine frame to prevent EMI/RFI interference.

• Power Supply: Ensure the DC power source is within the 10-49V range. While the switch supports redundant power, both sources should be verified for stability.

Product Applications

• Railway and Transportation: Used in rolling stock for passenger information systems, onboard Wi-Fi, and surveillance due to its EN50155 vibration standards.

• Food and Beverage: Ideal for “wash-down” areas where equipment is frequently cleaned with high-pressure water jets.

• Mining and Heavy Equipment: Mounted directly on mobile mining machinery to handle data from various sensors and cameras in dusty, high-vibration conditions.

• Maritime: Used in shipboard automation where salt air and humidity are prevalent.
