NI9361 National Instruments Processor module

Description

NI9361 National Instruments Processor module

Product Dimensions：

Product Description

The NI 9361 is a 32-bit counter module featuring 8 digital input channels. It is highly versatile, supporting both differential (RS-422/RS-485 level) and single-ended (TTL/Industrial 24V) signals. Its primary purpose is to handle high-speed pulse trains from encoders, flow meters, and proximity sensors, allowing for sophisticated position and velocity tracking.

Product Parameters

Key Advantages

• High Density: Allows for up to 64 counters in a single 8-slot CompactDAQ chassis, far exceeding the standard 4 backplane counters.

• Flexible Signal Support: The internal switchable 1 kΩ pull-up resistor allows direct connection to open-collector or push-pull sensors without external hardware.

• Advanced Measurements: Supports Dynamic Averaging, which optimizes frequency measurements for both high accuracy and low latency across a wide range (0 Hz to 1 MHz).

• Encoder Support: Specifically designed for incremental encoders, supporting quadrature encoding (A, B) and Z-index reloading for precise position sensing.

• Synchronization: Easily synchronized with other C Series analog or digital modules within the same chassis for time-correlated data acquisition.

Precautions & Maintenance

• Overvoltage Protection: The module supports up to 30 V DC input protection on DI+ terminals. Exceeding this may damage the internal circuitry.

• External Power (Vsup): When using the Vsup pin to power the internal pull-ups, note that the NI 9361 does not provide overvoltage protection for the external supply connection.

• Mounting: To meet the specified shock and vibration ratings (5 g vibration / 50 g shock), the system must be panel-mounted.

• Wiring: For single-ended modes, always leave the DI- terminal open and connect the signal to DI+ to ensure the programmable threshold functions correctly.

Product Applications

1. Motion Control & Robotics: Monitoring motor position and velocity using quadrature encoders.

2. Flow Measurement: Reading high-frequency pulse outputs from turbine or gear flow meters.

3. Automotive Testing: Measuring engine RPM, wheel speed, and fuel flow rates.

4. Production Line Monitoring: Counting parts or measuring conveyor speeds using proximity or Hall-effect sensors.

5. PWM Analysis: Measuring duty cycles and pulse widths for power electronic testing.
