PCI-6031E National Instruments multifunction data acquisition (DAQ) board

Description

PCI-6031E National Instruments multifunction data acquisition (DAQ) board

Product Dimensions：

Product Description

The NI PCI-6031E is a versatile, high-resolution, multifunction data acquisition (DAQ) device for the PCI bus. It is part of the E Series family and is designed for a wide array of measurement and control applications, from laboratory automation to production testing. The PCI-6031E provides a comprehensive set of I/O capabilities, including analog input, analog output, digital I/O, and counter/timers, on a single board.

Product Specifications

• Bus Connector: PCI
• Analog Input:
  • Channels: 64 single-ended or 32 differential, software-selectable.
  • Resolution: 16 bits.
  • Maximum Sample Rate: 100 kS/s.
• Analog Output:
  • Channels: 2.
  • Resolution: 16 bits.
  • Output Rate: 100 kS/s.
  • Output Range: $\pm$10 V.
• Digital I/O:
  • Channels: 8 TTL-compatible lines.
• Counters/Timers:
  • Channels: 2, 24-bit.
• Connector: 100-pin female 0.050 D-Type connector.

Product Advantages

• High Channel Count: With 64 analog input channels, the PCI-6031E is an excellent choice for applications that require a large number of measurements, such as monitoring multiple sensors in a process or testing many points on a circuit.
• Multifunctionality: This single card provides a complete set of I/O functions, including analog input, analog output, digital I/O, and timing. This reduces the need for multiple boards and simplifies system integration.
• High Resolution: The 16-bit resolution on both analog input and output channels ensures accurate and precise measurements and signal generation, making it suitable for demanding applications.
• Integration with NI Software: The PCI-6031E is fully supported by NI’s software platforms, including NI-DAQmx and LabVIEW, which provides a powerful and easy-to-use environment for configuring, programming, and analyzing your data.

Product Applications

The NI PCI-6031E is a versatile tool used in a wide range of applications:

• Laboratory Automation: Automating experiments and data logging in research and academic environments.
• Production Test: Integrating into automated test equipment (ATE) for manufacturing and quality control.
• Design Verification: Prototyping and testing electronic circuits and systems.
• Sensor Measurement: Acquiring data from a large number of sensors simultaneously in applications such as structural health monitoring or environmental monitoring.

Precautions

To ensure safe and reliable operation of the NI PCI-6031E, keep the following in mind:

• Cable and Connector: The device’s 100-pin connector requires a compatible cable and terminal block for proper field wiring. Using a shielded cable is highly recommended to maintain signal integrity and reduce noise.
• ESD Precautions: The device contains sensitive electronic components. Always handle the card in a static-safe environment and follow proper electrostatic discharge (ESD) procedures to prevent damage.
• Power Requirements: The board operates on +5 VDC and requires a stable power source. Ensure your PC’s power supply meets the specified requirements.
• Calibration: For applications requiring high accuracy, periodic calibration of the device is recommended to compensate for any long-term drift.
