PXIE-1073 National Instruments Central control module

Description

PXIE-1073 National Instruments Central control module

Product Dimensions：

Product Description

The PXIe-1073 is an entry-level, high-value chassis that combines a high-bandwidth backplane with an integrated MXI-Express interface. This design saves one peripheral slot, giving you more room for instrumentation while keeping the overall system footprint small and cost-effective.

Product Parameters

The PXIe-1073 is optimized for portability and high-speed data streaming to a host PC.

Product Advantages

• Integrated MXI-Express: You don’t need to buy a separate PXI Express controller. The chassis includes a built-in cabled interface that connects directly to a PC or laptop via a PCIe/ExpressCard adapter.

• Cost-Efficient: By integrating the controller and offering 5 slots, it provides a lower entry price point for PXI Express technology compared to larger 18-slot chassis.

• Compact Footprint: Its small size makes it ideal for “benchtop” testing, portable field diagnostics, or space-constrained laboratory environments.

• Acoustic Quietness: Designed to be relatively quiet, making it suitable for office or laboratory settings where fan noise can be a distraction.

• Reliable Timing: Includes the standard PXI 10 MHz reference clock and trigger lines to ensure all your modules stay perfectly synchronized.

Key Considerations (Precautions)

• Slot Limitation: With only 5 slots, it is not intended for massive, high-channel-count systems. Plan your module selection carefully.

• Non-Hot-Swappable: You must power down the chassis and the host PC before connecting or disconnecting the MXI-Express cable to avoid damaging the interface or the OS crashing.

• Power Per Slot: While it supports most modules, high-power modules (like some high-speed FPGAs) may have specific cooling requirements. Ensure the total power draw stays under 300W.

• Compatibility: The slots are PXI Express Peripheral Slots. They support PXI Express modules and “PXI Hybrid” modules, but they do not support older, legacy-only PXI modules.

Product Applications

1. Portable Validation: Using a laptop and an ExpressCard adapter to perform on-site vibration or structural analysis.

2. Small Automated Test Systems: Ideal for testing consumer electronics where only a DMM, a Scope, and a Switch module are needed.

3. Academic Labs: Providing students with a professional-grade PXI environment for signal processing or circuit design experiments at a lower cost.

4. Hardware-in-the-Loop (HIL): Small-scale simulation for ECU testing or sensor validation.
