SACB-8/16-10,0PUR .SCOP PHOENIX Central control module

Description

SACB-8/16-10,0PUR .SCOP PHOENIX Central control module

Product Dimensions：

Product Description

The SACB-8/16-10,0PUR SCOP is an 8-slot M12 sensor/actuator box that facilitates the connection of up to 16 signals (2 signals per slot) to a master control system via a single master cable. It acts as a centralized distribution node, replacing the need for long, individual cables from every sensor back to the control cabinet. This specific model comes with a 10-meter permanently connected PUR (Polyurethane) master cable and utilizes the SPEEDCON fast-locking technology.

Product Parameters

• Number of Slots: 8

• Number of Positions: 5 (supports 2 signals per M12 socket)

• Connection Method: M12 SPEEDCON fast locking

• Master Cable Length: 10.0 meters

• Master Cable Type: PUR (Halogen-free, suitable for drag chains)

• Nominal Voltage: 120 V AC/DC

• Current Carrying Capacity: 2 A per signal / 12 A total (at 40°C)

• Degree of Protection: IP65 / IP67

• Ambient Temperature: -25°C to 80°C (Fixed installation)

• Housing Material: PBT (Polyester)

Product Advantages

• Time Saving: The SPEEDCON system allows for a “Plug & Turn” connection, reducing assembly time by up to 90% compared to standard M12 threads.

• Space Optimization: Centralizing 16 signals into one master cable significantly reduces the space required in cable ducts and through-wall glands.

• High Durability: The PUR cable jacket is highly resistant to oils, chemicals, and mechanical wear, making it ideal for harsh industrial environments and robotic applications.

• Signal Clarity: Integrated status indicators (LEDs) for supply voltage and signal status allow for immediate visual diagnostics at the machine level.

• Reliability: Gold-plated contacts ensure low contact resistance and long-term signal integrity, even in vibration-prone environments.

Precautions for Use

• Cable Bending Radius: When installing the master cable in a drag chain, ensure the minimum bending radius is maintained (typically 10 x diameter) to prevent internal wire breakage.

• Slot Sealing: All unused M12 slots must be covered with appropriate screw plugs to maintain the IP67 protection rating against moisture and dust ingress.

• Tightening Torque: While SPEEDCON is a fast-locking system, ensure it is fully engaged to ensure a gas-tight seal and reliable electrical contact.

• Load Limits: Do not exceed the maximum total current of 12 Amps across the entire box to prevent overheating of the master cable.

Product Applications

• Automotive Assembly: Connecting multiple proximity sensors and limit switches on robotic welding or assembly lines.

• Packaging Machinery: Distributing signals for photoelectric sensors and solenoid valves across large conveyor systems.

• Machine Tool Construction: Centralizing I/O points in CNC machines where space is limited and cables are exposed to cutting fluids.

• Material Handling: Simplified wiring for automated storage and retrieval systems where long cable runs are necessary.
