X20AO2437 B&R Analog Output Module

Description

X20AO2437 B&R Analog Output Module

Product Dimensions：

Product Description

The B&R X20AO2437 is a 2-channel analog output module from the X20 System series. This module is designed to provide high-precision analog signals for industrial control applications. As part of the modular X20 system, it can be easily integrated into a larger B&R control system to extend its I/O capabilities.

This module is capable of generating two independent analog output signals. It supports a wide range of standard analog outputs, including voltage (0-10 V) and current (0-20 mA), making it versatile for different types of actuators and control devices. The module features an internal circuit for providing an electrical voltage to the outputs, which simplifies wiring. The signals have a high resolution of 16 bits, ensuring fine-grained control and accuracy.

Product Parameters

• Series: X20 System
• Product Type: Analog Output Module
• Channels: 2 analog outputs
• Output Ranges:
  • Voltage: 0-10 V (adjustable range)
  • Current: 0-20 mA (adjustable range)
• Resolution: 16-bit
• Data Transfer: 16-bit
• Electrical Isolation: The outputs are electrically isolated from the bus and the internal electronics.
• Accuracy: Better than 0.1% of the full scale
• Cycle Time: As fast as 400 µs
• Connections: The module uses removable terminal blocks for easy wiring.

Product Advantages

• High Precision: The 16-bit resolution and high accuracy make it suitable for applications that require very fine control, such as in process control or motion systems.
• Versatility: The ability to configure each channel for either voltage or current output simplifies inventory and provides flexibility for different applications.
• Robust Design: Electrical isolation protects the module and other system components from electrical noise and ground loops, which is essential for reliable operation in an industrial environment.
• Modular and Scalable: As part of the X20 System, it can be easily integrated into a larger control system. You can add or remove modules as your application needs change.

Important Notes

• System Compatibility: This module requires a B&R X20 controller and a bus system to function. It is not a standalone device.
• Wiring: While the module uses removable terminal blocks, proper wiring is crucial. Always follow the manufacturer’s manual for correct connection of power, signal, and ground.
• Configuration: The output range and other parameters must be configured in the B&R software (e.g., Automation Studio) to match the specific requirements of the application.

Product Applications

The X20AO2437 is widely used in applications where precise analog control is required.

• Process Control: For controlling variables like temperature, pressure, or flow using valves or heating elements.
• Motion Control: In systems where an analog signal is used to control the speed of a variable frequency drive (VFD) or the position of an actuator.
• Environmental Control: In HVAC systems to regulate fan speed or damper positions.
• Machine Automation: Used to control a wide range of machine functions that require a variable output signal.
