X20BB80 B&R Coated modules

Description

X20BB80 B&R Coated modules

Product Dimensions：

Product Description

The B&R X20BB80 is a crucial component within the B&R X20 I/O system, serving as the bus base terminal block. It is not an electronic module itself, but rather the foundation for B&R bus controllers and power supply modules. The X20BB80 provides the physical and electrical connection between the electronic X20 modules and the system’s backplane, which is typically mounted on a DIN rail. This bus base is designed for both data and power transmission, and its clever design allows for quick, tool-free installation and replacement of modules.

Product Parameters

The X20BB80 is characterized by its foundational role and robust design. Key technical specifications include:

• Function: Bus base for X20 bus controllers and power supply modules
• Mounting: 35 mm DIN rail
• Compatibility: Universal for all B&R X20 electronic modules
• I/O Power Supply: 24 VDC nominal voltage
• Permissible Contact Load: 10 A
• Operating Temperature: -25°C to 60°C (horizontal mounting)
• Degree of Protection: IP20
• Certifications: CE, UL, cULus, ATEX Zone 2, and more

The product comes with the necessary left and right locking plates (X20AC0SL1/X20AC0SR1) to secure the modules in place.

Product Advantages

The B&R X20BB80 offers several significant benefits that streamline system design and maintenance:

• Fast and Easy Installation: Its snap-on design allows for quick, tool-free mounting of modules, which dramatically reduces installation time and effort.
• Universal Compatibility: This single bus base works with all B&R X20 electronic I/O modules, simplifying inventory management and system design.
• Robust and Reliable: Built for harsh industrial environments, its rugged design and secure connections ensure long-term reliability and a high degree of operational safety.
• Space-Saving Design: The compact form factor supports high-density installations, allowing you to create more compact control panels and machine designs.
• Flexible Mounting: The module can be mounted either horizontally or vertically, providing more flexibility in panel layout.

Applications

As a foundational component, the X20BB80 is essential in any application that uses B&R’s X20 I/O system. Its primary role is to provide the backbone for the system. Common applications include:

• Industrial Automation: Serving as the base for modular I/O setups in manufacturing and process control.
• Machine Control: Providing the communication and power foundation for high-speed signal exchange in machinery.
• OEM Equipment: Enabling a cost-effective and scalable modular base for custom machinery.
• Control Panels: Allowing for a compact layout and easy module swapping for maintenance or upgrades.

Precautions

While the X20BB80 is designed for reliability, it’s important to follow a few precautions for optimal performance:

• Proper Mounting: Ensure the bus base is securely mounted on the DIN rail to prevent movement and ensure a stable connection.
• Correct Power Supply: Connect the module to a stable 24 VDC power supply with the correct specifications to prevent damage.
• Environmental Conditions: Operate the module within its specified temperature and humidity ranges. Note that the maximum operating temperature is 60°C for horizontal mounting and 50°C for vertical mounting.
• Module Compatibility: While the X20BB80 is universally compatible, always ensure the electronic modules you are installing are from the B&R X20 series.
