X20CA0E61.01500 B&R Analog output module

Description

X20CA0E61.01500 B&R Analog output module

Product Dimensions：

Product Description

The X20CA0E61.01500 is a Powerlink/Ethernet expansion cable primarily used to connect X20 system blocks or to extend the X20 backplane across different mounting rails. The “01500” in the part number indicates the cable length is 1.5 meters.

It features high-quality shielding and industrial-grade connectors designed to maintain signal integrity in environments with high electromagnetic interference (EMI).

Product Parameters

Product Advantages

• Seamless Integration: Designed specifically for the X20 System, ensuring “Plug & Play” compatibility with X20BC (Bus Controllers) and X20PS (Power Supply) modules.

• High Noise Immunity: Superior shielding prevents data packet loss in proximity to high-voltage motor cables or frequency inverters.

• Durability: The PUR jacket is designed for harsh industrial environments, offering resistance to oils, chemicals, and mechanical stress.

• Optimized Timing: Engineered to support the low-latency requirements of Ethernet POWERLINK, which is critical for synchronized motion control.

Product Application

This cable is essential in modular machine designs where the X20 I/O system is split across multiple sections:

• Cabinet-to-Cabinet Links: Connecting X20 stations located on different DIN rails within a large control cabinet.

• Modular Machines: Connecting a main control rack to a remote I/O station on a separate machine module.

• Distributed I/O: Used in systems where the PLC is central, but I/O nodes are distributed near sensors and actuators to reduce wiring costs.

Important Notes & Precautions

• Bending Radius: Do not exceed the minimum bending radius during installation. Repeated tight bending can damage the internal shielding and cause intermittent communication faults.

• Length Constraints: 1.5 meters is a fixed length. Do not attempt to cut or splice the cable, as this will change the impedance and likely cause system bus errors.

• Secure Latching: Ensure the connectors “click” into place on the X20 modules. A loose connection on the system bus can lead to a “Bus Module Missing” error in B&R Automation Studio.

• Routing: Even though it is shielded, avoid routing the cable directly parallel to high-power AC lines (e.g., 480V) for long distances to ensure maximum signal reliability.
