X20CP0483 B&R controller module

Description

X20CP0483 B&R controller module

Product Dimensions：

Product Description

The B&R X20CP0483 is a compact yet powerful controller module from the B&R X20 system. It’s designed to function as a complete and independent control unit, featuring an integrated CPU and a variety of interfaces. This controller is engineered to handle demanding automation tasks with high performance, making it a versatile choice for a wide range of industrial applications. Its compact design allows for direct integration into the modular X20 I/O system, creating a highly scalable and space-saving control solution.

Product Parameters

The X20CP0483 controller is defined by its core technical specifications:

• CPU: Intel Atom E6xx series (or similar high-performance, low-power CPU).
• Memory: 512 MB DRAM and 2 GB onboard flash memory.
• Interfaces:
  • POWERLINK: 2x RJ45 (integrated 2-port hub).
  • USB: 1x USB 2.0.
  • Ethernet: 1x RJ45 10/100 Mbit/s.
• Operating System: B&R Automation Runtime.
• Operating Temperature: -25°C to 60°C.
• Power Supply: 24 VDC.
• Mounting: On a bus base, with the ability to expand with X20 I/O modules.

Product Advantages

The B&R X20CP0483 offers several key benefits for industrial automation:

• High Performance: The integrated Intel Atom CPU and ample memory allow it to handle complex and time-critical applications, including motion control and robotics.
• Integrated Communication: With built-in POWERLINK and Ethernet interfaces, it enables high-speed, real-time communication for deterministic control and flexible network topologies.
• Compact and Modular Design: As part of the X20 system, it combines a controller and I/O into a single, space-saving unit. This modularity allows for easy expansion and a flexible system design.
• Reliability: Built to B&R’s high industrial standards, it’s designed to be reliable and durable in harsh industrial environments.
• Easy Engineering: The controller is programmed using B&R’s Automation Studio, a powerful and intuitive software environment that simplifies development, configuration, and diagnostics.

Applications

The X20CP0483 is a versatile controller that can be used in a wide range of industrial applications, including:

• Machine Control: Serving as the central brain for complex machinery, such as CNC machines, packaging lines, and textile machines.
• Robotics: Controlling robotic arms and end-of-arm tooling in high-speed pick-and-place applications.
• Automated Test Benches: For high-precision measurement, data acquisition, and control of test sequences.
• Process Automation: Managing and controlling small-to-medium-scale processes in industries like food and beverage, pharmaceuticals, and chemicals.

Precautions

To ensure the safe and reliable operation of the B&R X20CP0483, follow these important guidelines:

• Bus Base: The module requires a separate bus base, such as the X20BB81 or X20BB82, for mounting and electrical connection. This must be ordered separately.
• Power Supply: Connect the controller to a stable and correctly specified 24 VDC power supply.
• Environmental Conditions: Operate the module within its specified temperature range and ensure adequate ventilation to prevent overheating.
• Firmware and Software: Always use the latest firmware and a compatible version of B&R’s Automation Studio to ensure full functionality and security.
• Documentation: For detailed installation, programming, and safety information, always refer to the official B&R user manuals and datasheets.
