X20CP1483 B&R high-performance CPU module

Description

X20CP1483 B&R high-performance CPU module

Product Dimensions：

Product Description

The B&R X20CP1483 is a high-performance, compact controller module designed for B&R’s modular X20 I/O system. This module integrates a powerful Intel Atom E6xx series CPU and a comprehensive range of interfaces, making it a complete and independent control unit. It’s engineered to handle demanding and time-critical automation tasks with ease, including motion control and robotics. Its ability to directly integrate into the X20 I/O system allows for a highly scalable, space-saving, and flexible control solution.

Product Parameters

The key technical specifications for the B&R X20CP1483 include:

• CPU: Intel Atom E6xx series, ensuring high processing power.
• Memory: Features 512 MB of DRAM and 2 GB of internal flash memory for programs and data.
• Interfaces:
  • POWERLINK: 2x RJ45 with an integrated 2-port hub for real-time communication.
  • USB: 1x USB 2.0.
  • Ethernet: 1x RJ45 10/100 Mbit/s.
  • X2X Link: The module itself is a bus controller for the X2X Link, connecting to I/O modules.
• Operating System: B&R Automation Runtime.
• Power Supply: 24 VDC.
• Mounting: Designed to be mounted on a separate X20 bus base (e.g., X20BB81), allowing for easy expansion with X20 I/O modules.

Product Advantages

The B&R X20CP1483 offers several significant benefits for industrial automation:

• High Performance: The powerful Intel Atom CPU and a generous memory configuration enable the controller to execute complex and demanding control algorithms, including multi-axis motion and robotics.
• Integrated Real-Time Communication: With built-in POWERLINK and an integrated 2-port hub, it provides high-speed, deterministic communication and simplifies network wiring for flexible topologies.
• Compact and Modular Design: As part of the X20 system, it combines the controller and I/O into a single, space-efficient unit. This modularity allows you to easily scale your system by adding I/O modules as needed.
• Robustness and Reliability: Built to B&R’s stringent industrial standards, it is designed for a long service life in harsh industrial environments.
• Simplified Engineering: The controller is programmed using B&R’s Automation Studio, a powerful and intuitive software environment that streamlines development, configuration, and diagnostics.

Applications

The X20CP1483 is a versatile controller suitable for a wide range of industrial applications, including:

• Machine Control: Serving as the central control unit for complex machinery, such as CNC machines, packaging lines, and printing presses.
• Robotics: Controlling robotic arms, end-of-arm tooling, and other components in high-speed, precision-oriented applications.
• Process Automation: Managing and controlling small-to-medium-scale processes in industries like food and beverage, pharmaceuticals, and chemicals.
• Test and Measurement: Used in automated test benches for high-precision data acquisition and control of test sequences.

Precautions

To ensure the safe and reliable operation of the B&R X20CP1483, please follow these important guidelines:

• Bus Base: This module requires a separate bus base, such as the X20BB81 or X20BB82, for mounting and electrical connection. This must be ordered separately.
• Power Supply: Connect the controller to a stable and correctly specified 24 VDC power supply.
• Environmental Conditions: Operate the module within its specified temperature range and ensure adequate ventilation to prevent overheating.
• Firmware and Software: Always use the latest firmware and a compatible version of B&R’s Automation Studio to ensure full functionality and security.
• Documentation: For detailed installation, programming, and safety information, always refer to the official B&R user manuals and datasheets.
