X20IF2792 B&R Output module

Description

X20IF2792 B&R Output module

Product Dimensions：

Product Description

The X20IF2792 is a modular interface card that allows an X20 CPU or industrial controller to act as a Managing Node (MN) or Controlled Node (CN) within a POWERLINK network. It features an integrated 2-port hub, which simplifies daisy-chain cabling and ensures high-speed, real-time data synchronization across the automation system.

Product Parameters

Key Product Advantages

• Real-Time Performance: Utilizes the POWERLINK protocol to provide deterministic communication, essential for high-speed motion control.

• Integrated Hub: The dual ports allow for flexible network topologies (line or star) without the need for additional external switches.

• Compact Design: Fits seamlessly into the X20 CPU interface slot, saving valuable space in the control cabinet compared to standalone gateways.

• Easy Configuration: Fully integrated into the B&R Automation Studio software environment for simplified diagnostics and setup.

• Modular Scalability: Allows users to add specialized communication capabilities only when needed, reducing initial hardware costs.

Important Considerations (Precautions)

• Slot Limitation: Ensure your specific X20 CPU model has an available IF (Interface) slot; not all base modules support these expansion cards.

• Firmware Version: Ensure the CPU firmware and Automation Studio version support the X20IF2792 to avoid “Hardware Not Recognized” errors.

• Cable Quality: For 100 Mbit/s POWERLINK communication, high-quality shielded Cat5e (or better) industrial Ethernet cables are required to prevent EMI interference.

• ESD Handling: Like all X20 components, the module is sensitive to static electricity. Always wear an ESD wrist strap during installation.

Applications

• High-Speed Motion Control: Synchronizing multiple servo drives in packaging or printing machinery.

• Distributed I/O: Connecting remote X20 I/O stations to a central controller with sub-millisecond precision.

• Machine-to-Machine (M2M): Enabling high-speed data exchange between different machine cells in a production line.

• Robotics: Integrating robotic arms into a centralized control architecture where timing is critical.
