X20PS9400 B&R Power Supply Module

Description

X20PS9400 B&R Power Supply Module

Product Dimensions：

Product Description

The B&R X20PS9400 is a power supply module designed for the B&R X20 automation system. This compact module provides the necessary 24 VDC power for the bus controller, X2X Link, and internal I/O supply. It is specifically designed to be used with a 12-pin X20 terminal block and an X20 bus base. The module’s compact, DIN rail-compatible design helps to save space in control cabinets.

A key feature is the electrical isolation between the power supply feed and the bus controller/X2X Link supply, which enhances system reliability. It also supports redundant operation by allowing multiple supply modules to run simultaneously. For diagnostics and configuration, the module includes an RS232 service interface with LED status indicators for overload, operating status, and module status.

Product Parameters

• Attribute	Value
  Input Voltage	24 VDC (-15% / +20%)
  Input Current	Max. 0.7 A
  Output Voltage	24 VDC
  Nominal Output Power	7 W
  Output I/O Current	Max. 10 A (permissible contact load)
  Interfaces	1x RS232 service interface
  Dimensions (W x H x D)	37.5 mm x 99 mm x 73.5 mm
  Weight	Approx. 150 g
  Operating Temperature	-25 to 60°C (horizontal mounting)
  Mounting	DIN rail
  Protection	Integrated electronic fuse, short-circuit proof, temporary overload protection
  Certifications	CE, UL, cULus, RoHS, GOST-R

Product Advantages

• High Reliability: The module offers electrical isolation and the ability to set up redundant power supplies, which significantly increases system reliability and uptime.
• Space-Saving Design: Its compact footprint and DIN rail mounting save valuable space in industrial control cabinets.
• Easy Integration: Designed specifically for the B&R X20 system, it integrates seamlessly with other X20 modules and bus controllers.
• Built-in Diagnostics: Integrated LED indicators and a service interface make it easy to monitor the module’s status and perform diagnostics.
• Robust and Durable: With a wide operating temperature range and internal electronic protection, the module is built to withstand demanding industrial environments.

Precautions

• Required Accessories: You must order the X20TB12 terminal block and the X20BB8x bus base separately. The module cannot be used without them.
• I/O Power Supply: The I/O power supply input does not have reverse polarity protection. A maximum 10 A slow-blow fuse is required for the line to protect against short circuits.
• Fuses: The internal fuse for the bus controller/X2X Link power supply is integrated and cannot be replaced.
• Mounting Orientation: The operating temperature range varies depending on whether the module is mounted horizontally or vertically. Refer to the official datasheet for derating information at higher temperatures or elevations.

Product Applications

The B&R X20PS9400 is a core component for B&R X20 distributed I/O systems. Its primary applications include:

• Distributed Control Systems: Powering X20 I/O modules in machine-mount or cabinet setups.
• Automation Panels: Providing centralized or decentralized power distribution for automation systems.
• OEM Machinery: Used as an efficient and compact power supply in the control designs of original equipment manufacturers.
• Industrial Automation: Serving as a reliable power supply for programmable logic controllers (PLCs) and other associated devices within the X20 system.
